Observe the current consumption of the devi-
ces that are to be connected.
The diameter of the connections depends on the
current consumption, length of line and the ambi-
ent temperature of the unit. Information concern-
ing the current consumption can be found in the
Technical Data supplied with the particular unit to
be connected.
The following table lists the minimum diameters
of the connections in relation to the current con-
sumption:
Current consumption of
unit [A]
Cross-section
[mm
2
]
> 10 and < 16 1.5
> 16 and < 25 2.5
> 25 and < 32 4
> 32 and < 40 6
> 40 and < 50 10
> 50 and < 63 16
6.7 Information about connecting
cables
Mains supply cable
Installation type
Line layout (minimum
requirements)
Fixed installation – Plastic sheathed cable
(e.g. type NYM‑J)
Flexible – PVC flexible line
(e.g. H05 VV‑F)
or
– Rubber connection
(e.g. H05 RN‑F or
H05 RR‑F)
Display panel
Installation type
Line layout (minimum
requirements)
Fixed installation – CAT5.e network cable
Flexible – ISDN standard cable
with connectors
or
– Network patch cable
Control cable
Installation type Line layout (minimum
requirements)
Fixed installation – Shielded sheathed cable
(e.g. (N)YM (St)-J)
Flexible – PVC data cable with
shielded cable sheath-
ing, as used for tele-
communications and IT
processing systems
(e.g. type LiYCY)
or
– Lightweight PVC control
cable with shielded
cable sheathing
Assembly
9000-606-44/30 2011V003 17
