Assembly
6 Requirements
6.1 Installation/setup room
The room chosen for set up must fulfil the follow-
ing requirements:
– Closed, dry, well-ventilated room.
– Installation in purpose built rooms, e.g. in
boiler rooms, must be checked with local
building regulations first.
– Ambient temperatures are compliant with "4
Technical data".
NOTICE
Risk of overheating due to insufficient
ventilation
The units generates heat. Possibility of
heat damage and/or reduced service life
of the unit.
❯
Do not cover the unit.
❯
Install a fan for auxiliary ventilation in
rooms where ambient temperatures
exceed ³40 °C while the unit is in
operation.
6.2 Setup options
The following options for setting up the unit are
available:
– In a side room, in conjunction with a combina-
tion suction unit or in conjunction with a suc-
tion unit in a wet suction system with down-
stream separation.
– As a central amalgam separator in a dry suc-
tion system.
– In a ventilated cabinet (e.g. Power Tower) or
noise reduction hood.
– Upright on a level surface.
– Mounted upright on a Dürr wall holder.
– Mounted upright on a Dürr console for floor-
mounted installation.
6.3 Pipe materials
Only use vacuum-sealed HT-waste pipes
manufactured from the following materials:
– Polypropylene (PP),
– Chlorinated polyvinyl chloride (PVC-C),
– Unplasticized polyvinyl chloride (PVC-U),
– Polyethylene (PE).
The following materials must not be used:
– Acrylonitrile-butadiene-styrene (ABS),
– Styrene copolymer blends (e.g. SAN + PVC).
6.4 Hose materials
For waste connections and suction lines only
use the following hose types:
– Flexible spiral hoses made of PVC with inte-
grated spiral or equivalent hoses
– Hoses that are resistant to dental disinfectants
and chemicals
Plastic hoses will display signs of ageing
over time. Therefore, they should be
inspected regularly and replaced as nec-
essary.
The following types of hoses must not be
used:
– Rubber hoses
– Hoses made completely of PVC
– Hoses that are not sufficiently flexible
6.5 Pipe/hose installation
❯
Execute the on-site pipe installation in accord-
ance with the applicable local regulations and
standards.
❯
Lay the hose installation of the drains to or
from the unit at a sufficient incline.
If incorrectly laid, the hoses can
become blocked with sedimentation.
6.6 Information about electrical
connections
❯
Ensure that electrical connections to the mains
power supply are carried out in accordance
with current valid national and local regulations
and standards governing the installation of low
voltage units in medical facilities.
❯
Install an all-pole disconnect switch with a con-
tact opening width of at least 3 mm in the elec-
trical connection to the mains power supply.
