Function menu
Refer to Table 5-2 for the three levels of the nested menu
structure: Main Menu, Sub-Menu, and Parameter.
Table 5-2. Function Menu
Level 1 Main Menu Level 2 Sub-Menu Parameter Code
*Settings *Forward Direction Forward Set Voltage 001
Forward Bandwidth 002
Forward Time Delay 003
Forward Line Drop Comp. Resistance 004
Forward Line Drop Comp. Reactance 005
*Reverse Direction Reverse Set Voltage 051
Reverse Bandwidth 052
Reverse Time Delay 053
Reverse Line Drop Comp. Resistance 054
Reverse Line Drop Comp. Reactance 055
*Configuration Regulator Identification 040
Regulator Type 140
Tap Changer Type 049
Regulator Configuration 041
Control Operating Mode 042
System Line Voltage 043
Overall P.T. Ratio 044
C.T. Primary Rating 045
Demand Time Interval 046
P.I. ADD-AMP, High Limit 144
P.I. ADD-AMP, Low Limit 145
V
in
P.T., Configuration 146
*Calendar/Clock System Calendar and Clock 050
_Menu System Language Selection 141
Date Format 142
Time Format 143
*Features *Auto-Block Status Auto Operation, Blocking Status 069
*Reverse Power Mode Reverse Sensing Mode 056
Reverse Current, Sense Threshold 057
*Source Side,
Voltage Calculation
Source Voltage Calculation 039
*Voltage Limiter Voltage Limiter Mode 080
High Voltage Limit 081
Low Voltage Limit 082
*Voltage Reduction Voltage Reduction Mode 070
Reduction in Effect 071
Local/Digital Reduction Value 072
Remote #1 Value 073
30
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
