Special functions
Use these functions to perform commands through the
menu or function code system.
Master Reset – FC 38
Initial Press Reset Message
Entering FC 38 or accessing this command via the menu
system will cause the LCD to display the following message:
While the (PRESS RESET) message is displayed, pressing
the Escape key causes the LCD to exit the viewing of this
command and to display the previous sub-menu items. Or,
pressing the Edit/Reset button will request a "Confirm"
before resetting all demand metering and tap position
maximum and minimum values.
Confirm message
While the (CONFIRM) message is displayed:
pressing the Escape key causes the LCD to display the
initial (PRESS RESET) message; pressing the Enter key
causes the execution of the command and the LCD will
display (DONE).
Done message
While the (DONE) message is displayed:
pressing the Escape or Enter key will cause the LCD to exit
the viewing of this command and to display the previous
sub-menu items.
Enter security code - FC 99
Entering FC 99 as follows:
causes the menu system to enter the security code mode:
This function code does not have an item in the menu
system.
Self-test - FC 91
Using the Self-Test, FC 91, will reboot the system. After
pressing Function, 9-1-Enter and accessing the FC 91
display, press Enter again to select the option and again to
confirm. When the reboot is complete, the LCD displays the
startup screen. Press Escape for further keypad use.
Test LEDs
Access this from the Main Menu (Level 1). With the cursor
selecting “Test LEDs” in the main menu, press the Enter key
and the front panel LEDs will blink three times. The Com port
and Neutral Light LEDs do not blink.
Turn display off
Access this from the Main Menu (Level 1). With the cursor
selecting “Turn Display Off” in the main menu, press the
Enter key and the LCD display will turn off. To turn on the LCD
display, press any button in the keypad.
Alarms
Use the nested menu to access the lists of acknowledged
and unacknowledged system alarms. No security code is
needed to display an alarm; a security code is needed to
acknowledge an alarm.
•
Alarms/Events > Alarms Active Unacknowledged
This displays a list of active, unacknowledged system
alarms.
•
Alarms/Events > Alarms Active Acknowledged
This displays a list of active, acknowledged system
alarms.
This section covers Alarm displays; for more information, see
the Advanced Features: Alarms section of this manual.
038 Master Reset
(PRESS RESET)
038 Master Reset
(CONFIRM)
038 Master Reset
(DONE)
Function Code
_99
Security Code
-----
71
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
