Displayed when the user accesses Compact Flash
operations:
•
(WRITING)
•
(WRITING COMPLETE)
•
(WRITING FAILED)
•
(WRITING ABORTED)
•
(LOADING...)
•
(LOADING COMPLETE)
•
(LOADING FAILED)
•
(LOADING ABORTED)
•
(SAVING...)
•
(SAVING COMPLETE)
•
(SAVING FAILED)
•
(SAVING ABORTED)
•
(FORMATTING...)
•
(FORMATTING COMPLETE)
•
(FORMATTING FAILED)
•
(FORMATTING ABORTED)
Displayed when indicating that the values for Load Voltage
Secondary and Source Voltage Secondary have been derived
by the control:
•
(CALCULATED)
Displayed when indicating inconsistencies between the
neutral signal and Tap Position value entered by the user:
•
(TAP AT NEUTRAL)
•
(TAP NOT AT NEUTRAL)
Metering-PLUS formats
This section covers Metering-PLUS displays; for more
information, see the Advanced Features: Metering PLUS
section of this manual.
Compensated voltage
When the *Comp Voltage key is pressed while the control
is operating under Forward Power Flow conditions, the LCD
displays:
If the control is operating under Reverse Power Flow
conditions, the LCD displays:
When operating in the Cogeneration Mode, metering always
operates in the forward direction except that load center
voltage is calculated based upon the reverse line-drop
compensation settings when the fixed 1% reverse metering
threshold is exceeded. So, the LCD displays:
Load voltage
When the *Load Voltage key is pressed while the Voltage
Limiting Mode = High and Low Limits Active, the LCD
displays:
If Voltage Limiting Mode = Only High Limit, the LCD displays:
If Voltage Limiting Mode = Off, the LCD displays:
Load current
When the *Load Current key is pressed while the control is
operating under Forward Power Flow conditions and auto-
matic tapping is inhibited, the LCD displays:
Comp Voltage 125.0
Band 119.0-121.0
Using Func 1-5
Comp Voltage 115.0
Band 108.0-112.0
Using Func 51-55
Comp Voltage 123.0
Band 119.0-121.0
Using Func 1-3,54,55
Load Voltage 115.0
Limiter 119.0-121.0
Load Current 600 Fwd
Current Threshold 12
Mode Locked Forward
Blocked: TB8 - 4&5
Load Voltage 115.0
Limiter 121.0
Load Voltage 115.0
Limiter Off
75
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
