2.1 Setup of the Connection PC – Protective Device
PowerPort-E can receive data from the protective device only after the connection has been
set up. This needs to be done only once.
The following pages present an overview of the connection setup for the various types of
protective devices.
A detailed description can be found in the PowerPort-E manual, which is available as a
separate document on the product DVD, but can also be accessed directly from the Smart
view Help menu.
2.1.1 Optional Accessories
The type of cable required for the connection is dependent on the type of protective
device. The cables are not part of the product delivery, but can be ordered separately
from Woodward.
SmartV_Z22
SmartV_Z23
SmartV_Z24
USB cable, for protective
devices with USB front
connector.
Null Modem cable, for
protective devices with RS232
front connector.
Eaton article:
66B2214G01
USB/Serial adaptor, for
protective devices with RS232
front connector and PC
without RS232 connector.
Eaton article:
66B2214G02
13www.eaton.comE-Series Family Quick Start Guide
2 Quick Start – Operating Software PowerPort-E
2.1 Setup of the Connection PC – Protective Device
