Eaton Remote Power Panel User Manual

Installation
12 Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality
Figure 6. RPP Layout – Cooper Bussmann Panel
UCB
X-Slot Communication Bay 1
DB-9 Communication Port
Output Ground
Branch Fuses and
Disconnect Switches
Current Transformers (CTs)
(one row each side)
Casters and Leveling Feet
X-Slot Communication Bay 2
Output Neutral
200A Fuses
Distribution Panel
Disconnect Switch
Optional SPD
42-Circuit Distribution Panel

Eaton Remote Power Panel Specifications

General

Brand	Eaton
Model	Remote Power Panel
Category	Power distribution unit
Language	English
