Eaton Remote Power Panel User Manual

Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality 35
Chapter 5 Communication
Communication features are available only with the Energy Management System (EMS) System Level and
Premium metering.
This section describes the:
l
DB-9 communication port
l
X-Slot cards
l
Relay output contacts
l
Programmable signal inputs
Figure 19 shows the location of the communication options and control terminals on the Remote Power Panel
(RPP).
Figure 19. Communication Options and Control Terminals
X-Slot Communication Bay 1
X-Slot Communication Bay 2
DB-9 Communication Port
Control Terminals
Universal Control Board (UCB)

Eaton Remote Power Panel Specifications

General

Brand	Eaton
Model	Remote Power Panel
Category	Power distribution unit
Language	English
