Eaton Remote Power Panel User Manual

Installation
Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality 17
Figure 8. Wiring Input Connections (each side) for Direct Connect RPP
Phase A (top panel)
Phase B (top panel)
Phase C (top panel)
For chassis and
isolatd ground
connections, see
Figure 10 on page 19.
Ground
}
Ground CT
Phase A (bottom panel)
Phase B (bottom panel)
Phase C (bottom panel)
For chassis and
isolatd ground
connections, see
Figure 10 on page 19.
Ground
}
Ground CT
Neutral (top panel)
Neutral (bottom panel)
Top Panel Current CTs
(one per phase)
Bottom Panel Current CTs
(one per phase)
