Eaton Remote Power Panel User Manual

Installation
Eaton Remote Power Panel (RPP) User’s Guide 164202125—Rev 5 www.eaton.com/powerquality 13
Table 1. RPP Main Input Feed Conductor Coding and Termination (208V and 400V)
Configuration and
Terminal Functions
Panel Main Breaker
or Switch Rating
Terminal Function Size of Pressure Termination
Tightening Torque
Nm (lb in)
Direct Connection
to Panelboard
Main Breakers
225AF
A (Black) Phase A 1 – #6–500MCM 56 (500)
B (Red) Phase B 1 – #6–500MCM 56 (500)
C (Blue) Phase C 1 – #6–500MCM 56 (500)
N (White) Neutral 2 – #6–300MCM 31 (275)
G (Green) Ground 1 – #14–1/0 5.6 (50)
Direct Connection
to Panelboard
Main Breakers
400AF
A (Black) Phase A 2 – #6–500MCM 56 (500)
B (Red) Phase B 2 – #6–500MCM 56 (500)
C (Blue) Phase C 2 – #6–500MCM 56 (500)
N (White) Neutral 4 – #6–300MCM 31 (275)
G (Green) Ground 1 – #14–1/0 5.6 (50)
One Panelboard
Single MLO
Dual MLO
225AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 2 – #6–300MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
Two Panelboards
Single MLO
Dual MLO
225AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 4 – #2–600MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
One Panelboard
Single MLO
Dual MLO
400AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 4 – #2–600MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
Two Panelboards
Single MLO
Dual MLO
400AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 6– #2–600MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
Three Panelboards
Single MLO
225AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 6 – #2–600MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
Four Panelboards
Single MLO
225AF
A (Black) Phase A 4 – #6–300MCM 31 (275)
B (Red) Phase B 4 – #6–300MCM 31 (275)
C (Blue) Phase C 4 – #6–300MCM 31 (275)
N (White) Neutral 6 – #2–600MCM 56 (500)
G (Green) Ground 2 – #14–1/0 5.6 (50)
Isolated Ground
(if applicable)
All G (Green) Isolated Ground 1 – #6–300MCM 31 (275)
