EDAN M3 Service Manual

M3 Vital Signs Monitor Service Manual
- 7 -
1.4 Interfaces
For the convenience of operator, interfaces of different function are in different sites of the
monitor.
Left Side of the Monitor
At the left side of the monitor, there is the recorder’s paper inlet cover (①).
Figure1-5 Left Panel
Sensor port on the front panel
Connectors for cables and sensors are as shown in Figure 1-5.
1. SpO
2
sensor connector ②
2. NIBP cuff connector ③
WARNING
Only connect the device to EDAN supplied or recommended accessories.
Rear Panel
This symbol means “BE CAREFUL". Refer to the manual.
①
②
③
！
