M3 Vital Signs Monitor Service Manual
- 2 -
M3 Vital Signs Monitor can monitor:
NIBP: Systolic Pressure (SYS);
Diastolic Pressure (DIA);
Mean Pressure (MAP);
SpO
2
: Arterial oxygen saturation (SpO
2
);
Pulse Rate (PR);
SpO
2
PLETH (Plethysmogram)
The M3 monitor provides extensive functions as visual and audible alarm, recorder and storage
for trend data, SpO
2
/NIBP measurements review, net connection, nurse call, alarm events and so
on. The recorder, wireless net connection and mobile storage are optional functions for monitor.
1.2 Screen Display
M3 Monitor is equipped with LCD. The patient parameters, waveforms, alarm messages, bed
number, time, monitor status and other data can be reflected from the screen.
The screen is divided into three areas:
1 Parameter area ①
2 Waveform / Trend table / Alarm list area ②
3 Information area ③④
Figure1-2 Main display with waveform
①
②
③
④
