B722-40-880 Issue F
Page 16 © Edwards Limited 2013. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.9 Podule connector socket
The DX pump has a 2-way Podule Connector Socket in the top of the Podule. When the pump is shipped, this connector
is concealed by a black protective cover. If the connector will be used, this cover should be removed by levering with
a small screwdriver. The mating plug for this connector is supplied with the pump.
The connector is intended to drive a vent valve or fan connected to the two pins. The connector mating plug is shown
in Figure 4, with the polarity of the pins marked when the vent valve/fan is energised.
The podule connector plug is available as an accessory, see Section 7.4.
Analogue output:
Output voltage 0 to 10 V d.c. (directly proportional
to measured parameter)
Motor speed: 0 - 1500 Hz (0-100%)
Motor power: 0 - 120 W
Motor temperature: 0 - 100 °C
Controller temperature: 0 - 100 °C
0 to 10 V d.c. (directly proportional
to measured parameter)
Motor speed: 0 - 1000 Hz (0-100%)
Motor power: 0 - 200 W
Motor temperature: 0 - 100 °C
Controller temperature: 0 - 100 °C
Output current 5 mA 5 mA
NORMAL status output:
Type Open collector transistor Open collector transistor
< Normal speed (default 80%) Off (2.2 k pull up to 12 V d.c.) Off (2.2 k pull up to 12 V d.c.)
Normal speed On (<0.8 V d.c. sinking 20 mA) On (<0.8 V d.c. sinking 20 mA)
Rating 20 mA to 0 V 20 mA to 0 V
FAIL status output:
Type Open collector transistor Open collector transistor
Fail Off (3.3 k pull up to 12 V d.c.) Off (3.3 k pull up to 12 V d.c.)
OK On (<0.1 V d.c. sinking 1.7 mA,
<0.8 V d.c. sinking 20 mA)
On (<0.1 V d.c. sinking 1.7 mA,
<0.8 V d.c. sinking 20 mA)
Rating 20 mA to 0 V 20 mA to 0 V
*
Mating half of connector not supplied.
Table 9 - Logic interface technical data (continued)
Logic interface item EXT75DX EXT255DX
