Edwards EXT75DX User Manual

B722-40-880 Issue F
Page 42 © Edwards Limited 2013. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Operation
4.1.6 Timer setting and options
Refer to Section 1.4.3 for a full description of Timer functionality.
The time-out period is a user-configurable option and can be set to any value from 1 to 30 minutes. When the pump
is shipped, it is configured with a default time-out period of 8 minutes.
To change the Timer setting, send the following command (where the characters 'd' represent the time-out period in
minutes):
The reply will be as follows:
The Timer setting is now stored in memory within the DX pump.
To check what time-out period is set, send a query as follows:
The reply will be as follows:
The Timer is permanently enabled during ramp-up, however it is optional whether to have it enabled at other times.
When the pump is shipped, the Timer is enabled by default.
To disable the Timer, send the following serial command:
The reply will be as follows:
The state of the Timer option is stored in memory within the DX pump.
To enable the Timer again, send the following serial command:
The reply will be as follows:
To check whether the Timer is enabled or disabled, send the following query:
The reply will be as follows (where d=0 means disabled and d=1 means enabled):
Command ! S
8 5 4spd dcr
Reply * S 8 5 4sprcr
Command ? S 8 5 4cr
Reply = S 8 5 4spd dcr
Command ! S 8 7 0sp0cr
Reply * S
8 7 0sprcr
Command ! S
8 7 0sp1cr
Reply * S
8 7 0sprcr
Command ? S
8 7 0cr
Reply = S
8 7 0spdcr
