Emerson Micro Motion 4200 User Manual

3 Wiring the channels
3.1 Installation types for the 4200 transmitter
WARNING
If you are installing the transmitter in a hazardous area, refer to Micro Motion approval
instructions, shipped with the product or available from the Emerson web site
( Emerson.com/flowmeasurement). Improper installation in a hazardous area can cause
an explosion.
General configuration
A. 2-wire cable power and signal
B. 4-20 mA
C. mA receiving device
D. HART
®
variables
E. Distributed Control System (DCS)
F. Emerson AMS Trex communicator
Installation Manual Wiring the channels
MMI-20058013 March2024
Installation Manual 23
