Emerson Micro Motion 4200 User Manual

• ProLink III with ProcessViz Software User Manual
• Replacing the Junction Box for the 4200 Transmitter and the 5700 Transmitter
• Replacing the Sensor Cable for the 4200 Transmitter and the 5700 Transmitter
• Sensor installation manual, which is shipped with the sensor
• Failure Modes, Effects, and Diagnostic Analysis (FMEDA) report for Coriolis Flow Meter
with 4200 Transmitter, Prepared for Emerson by exida.com LLC
1.4 Meter components
A 4200 Meter consists of the following components:
• transmitter
• sensor
1.5 Installation types
The 4200 transmitter was ordered and shipped for one of two installation types. The fifth
character of the transmitter number indicates the installation type.
Figure 1-1: Installation type indication for 4200 transmitters
The number is located on the device tag on the side of the transmitter.
Table 1-1: Installation types for 4200 transmitters
Code Description
I Integral mount painted aluminum
C Remote mount painted aluminum
J Integral mount stainless steel
P Remote mount stainless steel
Planning Installation Manual
March2024 MMI-20058013
6 Micro Motion 4200 2-Wire Transmitter

Emerson Micro Motion 4200 Specifications

General

Brand	Emerson
Model	Micro Motion 4200
Category	Transmitter
Language	English
