22 Mentor MP User Guide
www.controltechniques.com Issue: 3
Figure 3-11 Size 2D front view and mounting dimensions
124m
m
(4.88
i
n
)
6mm
(0.24in)
1065mm (41.93in)
356mm (14.02in)
248mm (9.76in)
405mm (15.94in)
4mm
(0.16in)
321mm (12.64in)
330mm (13.0in)
555mm (21.85in)
330mm (13.0in)
330mm (13.0in)
452mm (17.8in)
202mm (7.95in)
390mm (15.35in)
