Section 8 • Spare Parts List
VSS/VSM/VSH/VSSH • Installation, Operation and Maintenance Manual • Emerson • 35391SD
Vilter parts get renewed from time to time, so be sure to ask if the part listed in your manual is still the best for your compressor.
Parts that appear on diagrams might be shown separately for reference, but are sold as an assembly or kit only.
8 − 37
Slide Valve Cross Shafts & End Plate
NOTE:
** Required at top locate single gaterotor only.
ITEM DESCRIPTION
MODEL NUMBER
QTY VSM 301 VSM 361 VSM 401 QTY VSM 501 VSM 601 VSM 701
-
OIL BAFFLE ASSEMBLY (1)
217, (1) 244, (1) 248, (1)
249, (1) 252
1 A25942AA A25942AA A25942AA 1 A26034B A26034B A26034B
SHIM ASSORTMENT (2) 240,
(2) 241, (1) 242, (1) 243
1 A25177A A25177A A25177A 1 A26035B A26035B A26035B
217 OIL BAFFLE PLATE 1 25938A 25938A 25938A 26045A 26045A 26045A
220 END PLATE. 1 25719D 25719D 25719D 1 26025B 26025B 26025B
221 SHAFT 2 25941A 25941A 25941A 2 25843A 25843A 25843A
222 GEAR. 4 25027A 25027A 25027A 4 25027A 25027A 25027A
227 CLAMP. 4 25913A 25913A 25913A - N/A N/A N/A
228 SPACER. 4 25847A 25847A 25847A 4 25847A 25847A 25847A
293 SHIM 0.002” AR 25409AA 25409AA 25409AA 2 26027BA 26027BA 26027BA
294 SHIM 0.003” AR 25409AB 25409AB 25409AB 2 26027BB 26027BB 26027BB
295 SHIM 0.005” AR 25409AC 25409AC 25409AC 1 26027BC 26027BC 26027BC
296 SHIM 0.010” AR 25409AD 25409AD 25409AD 1 26027BD 26027BD 26027BD
244 TEFLON RING 1 25939A 25939A 25939A 1 25929B 25929B 25929B
248 CHECK VALVE 1 3120A 3120A 3120A 1 3120A 3120A 3120A
249 CHECK VALVE 1 3120B 3120B 3120B 1 3120B 3120B 3120B
252 RETAINING RING 1 2829M 2829M 2829M 1 2928N 2928N 2928N
255 WASHER - N/A N/A N/A 2 25977E 25977E 25977E
256 WASHER - N/A N/A N/A 2 25977F 25977F 25977F
268 EXPANSION PIN. 4 1193D 1193D 1193D 4 1193D 1193D 1193D
269 EXPANSION PIN. 4 2981AA 2981AA 2981AA 4 2981AA 2981AA 2981AA
271** PLUG SOLID 1 25422A 25422A 25422A - N/A N/A N/A
281 HEX HEAD CAP SCREW. 6 2796N 2796N 2796N 8 2796B 2796B 2796B
286 SOCKET HEAD CAP SCREW. 8 2795F 2795F 2795F 2 2795D 2795D 2795D
297 SET SCREW. 2 2060J 2060J 2060J 2 2060J 2060J 2060J
298 SET SCREW. 2 2060H 2060H 2060H 2 2060H 2060H 2060H
NOTE:
** Required at top located single gaterotor only.
