SECTION 9: OPTIONAL FEATURES
Vector Cutting Table/Slat Table
Vector Cutting Table
The optional Vector Cutting Table is primarily used for vector
cutting jobs where the laser penetrates all the way through
the material being cut. The Vector Cutting Table lis your work
material o of the crumb trays and allows the laser beam to
penetrate all the way through the material without reflecting
back up onto the backside of your work.
On the Fusion Pro 48, a divided table allows you to use a vector
grid on half of the bed and engraving table on the other half
for increased versatility.
Slat Table
The optional Slat Table is a second option for vector cutting
jobs. The Slat Table has bars that are adjustable and removable
to help avoid any kind of grid marks appearing on the back of
the piece you’re engraving.
On the Fusion Pro 48, a divided table allows you to use a slat
table on half of the bed and engraving table on the other half
for increased versatility.
Whenever you are vector cutting there is the potential for small pieces to fall through the grid
and collect in the bottom of the Vector Cutting Table. These small pieces present a very
dangerous fire hazard. Remove and dispose of the debris in the Vector Cutting Table on a
regular basis.
- 127 -
