Connecting to an external monitor (EB-W9/X9/S9
only)
You can display computer images input from Computer Input Port on an
external monitor connected to the projector and the screen at the same
time. This means that you can check projected images on an external
monitor when giving presentations even if you cannot see the screen.
Connect using the cable supplied with the external monitor.
A
To Monitor port
B
Cable supplied with monitor
C
To Monitor Out Port
q
• You cannot display images from equipment connected to the
component video signal, Video input port, or S-Video input port on
the external monitor.
• Setting gauges, Configuration Menu, or Help screens for functions
such as Keystone are not output to the external monitor.
• If you want to display images on the external monitor while the
projector is in standby mode, set Extended - Standby Mode to
Communication On from the Configuration menu. s p.53
Connecting to External Equipment
86
