Epson EH-TW5910 User Manual

Preparing
20
Connecting WirelessHD devices (EH-TW6100W only)
The projector receives transmissions from the WirelessHD Transmitter, and projects the images. s p.49
Change the projected image by pressing the
button on the remote control or the button on the
control panel.
c
•
When receiving WirelessHD images, make sure WirelessHD is set to On. s Settings -
WirelessHD p.71
•
You can change which device is displayed by selecting a device from Device Connections in HDMI
Link.
s HDMI Link-Device Connections p.60
Removing the Interface Cover
The interface cover is attached to the connector section on the rear of EH-TW6100W. Remove this cover when
using a cable to connect a device.
There are gaps at the bottom of the interface cover that allows you to pull the cover forward and lift it from
the grooves at the top.
c
•
When reattaching, first insert the protruding sections into the grooves at the top.
•
Make sure you store the interface cover safely, as you need this when transporting the projector.
Connecting an HDMI Cable Clamp
If the HDMI cable is thick and hangs down, make sure you secure it to the cable holder with an HDMI clamp
so that the cable's weight does not disconnect it from the port.

Epson EH-TW5910 Specifications


color light output	2, 100 lumen
white light output	2, 100 lumen
resolution	1920 x 1080
contrast ratio	20, 000:1

Optical

projection ratio	1.32 - 2.15:1
projection size	30 inches - 300 inches
projection distance wide	0.9 m - 8.9 m
projection distance tele	1.4 m - 14.5 m

Power

energy use	358 W
economy energy use	274 W
standby energy use	0.35 W

Connectivity

interfaces	RS-232C, VGA in, HDMI 1.4 (2x), Composite in, USB 2.0 Type A, USB 2.0 Type B, Component in
loudspeaker	20 W
stereo	Stereo

Weight and Dimensions

product dimensions	420 x 365 x 137 mm
product weight	6 kg
noise level economy	24 dB (A)
