Epson EH-TW5910 User Manual

Preparing
21
Preparing the Remote Control
Installing the Remote Control Batteries
Attention
•
Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the
correct way.
•
You cannot use other batteries except for the AA size manganese or alkaline.
a
Remove the battery cover.
While pushing the battery compartment
cover catch, lift the cover up.
b
Replace the old batteries with new
batteries.
Check the polarity of the batteries (+ and -)
before installing.
c
Reattach the battery cover.
Press the cover until it clicks into place.
c
If delays in the responsiveness of the
remote control occur or if it does not
operate, it probably means that the
batteries are becoming flat. When this
happens, replace them with new
batteries. Have two AA size manganese
or alkaline batteries ready.
Remote Control Operating Range
The operation range for the WirelessHD Transmitter differs. s p.58
Operating range (left to right) Operating range (top to bottom)

Epson EH-TW5910 Specifications


color light output	2, 100 lumen
white light output	2, 100 lumen
resolution	1920 x 1080
contrast ratio	20, 000:1

Optical

projection ratio	1.32 - 2.15:1
projection size	30 inches - 300 inches
projection distance wide	0.9 m - 8.9 m
projection distance tele	1.4 m - 14.5 m

Power

energy use	358 W
economy energy use	274 W
standby energy use	0.35 W

Connectivity

interfaces	RS-232C, VGA in, HDMI 1.4 (2x), Composite in, USB 2.0 Type A, USB 2.0 Type B, Component in
loudspeaker	20 W
stereo	Stereo

Weight and Dimensions

product dimensions	420 x 365 x 137 mm
product weight	6 kg
noise level economy	24 dB (A)
