XT2+ Series DISK RECORDER - Version 10.05 - Hardware Technical Reference Manual

Issue

10.05.A

EVS Broadcast Equipment SA – July 2011

3. Hardware Description

3.1 BOARDS AND SLOT CONFIGURATIONS

The XT2+ server contains all EVS developed boards. The XT2+ server can be

fitted with COHX or V3X video boards. The board configuration will slightly vary

depending on the type of video board used.

Important

It is not allowed to mix COHX and V3X boards on the same EVS server.

3.1.1 SLOT CONFIGURATION WITH COHX BOARDS

Slot # XT2+ SD, HD or HD/SD

7 Disk Array or RSAS

6 HCTX

5 CODA (Audio Codec)

4 COHX (SD, HD or SD/HD) #3

3 COHX (SD, HD or SD/HD) #2

2 COHX (SD, HD or SD/HD) #1 Genlock

1 MTPC
