TF (transfer)

Blinks green while data transfers occur between the COD module and the

HCTX board

M1, M2, M3, M4 not yet used

GENERAL CONNECTIVITY ON THE V3X COD A AND COD B

MODULES

This section describes the connector assignments and layout for the video

standards SD 525i, SD 625i, HD 1080i and HD 720p.

The specific connectivity for HD 3D/1080p Dual Link and 3D/1080p single link

3Gbps is described in dedicated sections.

Changes in Connector Assignments from Multicam 10.04

On XT2+ servers equipped with DualPower V3X video codec boards, the

assignment of video connectors on the rear panel has been modified to reflect the

new configurations available from Multicam 10.04.

Consequently, the following changes are applied to the connectors:

• The center left connector of a group of video connectors on the rear panel is

initially connected to the J5 connector on the V3X module.

It should be connected to J1 if monitoring (CVBS or SDI) is required in SD or

HD mode.

Apply caution if you need to move the corresponding cable between J1 and J5

connectors on the V3X module: do not apply excessive traction or pressure,

and make sure pressure or traction is applied in the correct alignment of the

connectors, never sideways.

• The J3 connector, previously labelled ‘SD OUT’ and located on the center left

position, is now labelled ‘OUT B’ and located at the bottom right position.

From Multicam 10.04, it is the output for the left eye or link 2 when working

respectively with 3D or 1080p Dual Link formats.
