EVS XT2+ User Manual

Issue
10.05.A
XT2+ Series DISK RECORDER – Version 10.05 - Hardware Technical Reference
EVS Broadcast Equipment SA – July 2011
54
LEDS ON THE COHX BASE OF A V3X BOARD WITH GENLOCK
GLK
Off when the genlock module is not initialized
Blinks green when the genlock module is properly initialized, but not valid
genlock signal is detected
On, steady
green
when the module is initialized and a valid genlock signal is
detected
Red
(intermittent)
when there is a genlock problem
Red (steady) when a resync is needed
PSU OK
On (green) when all voltages are present and in the allowed range,
otherwise the led is off
LEDS ON THE V3X COD A AND COD B MODULES (FROM
LEFT TO RIGHT)
CPU
Blinks green to indicate CPU activity
On, steady
green
when there is a problem with the processor of the COD module
PLAY
On (green) when the COD module is set by the software in play mode
Off when the COD module is set in record mode
PVID
on (green) when a valid video signal has been detected on the J8
connector (SD/HD SDI input), whether the COD module is in
play or record mode
