EVS XT2+ User Manual

XT2+ Series DISK RECORDER - Version 10.05 - Hardware Technical Reference Manual
Issue
10.05.A
EVS Broadcast Equipment SA – July 2011
69
3750 G family, for example the WS-C3750G-24T-S.
For more information, refer to the Multicam Configuration manual for setting up
the IP addresses.
3.4.2 RCTL BOARD ON SAS DISK ARRAY (WITH HCTX)
Disk Arrays on systems with HCTX Boards have a controller on the disk array
board.
Different configurations can be used
• One internal array with a series of 6 disks
• One internal arrays with two stacked series of 6 disks,
• No internal storage
