EVS XT2+ User Manual

XT2+ Series DISK RECORDER - Version 10.05 - Hardware Technical Reference Manual
Issue
10.05.A
EVS Broadcast Equipment SA – July 2011
67
J
UMPERS
ST1-1 on controller module (front centre) : jumper must be installed on ST1-1 only
when the HCTX board is used with previous video codec boards (SD CODEC6,
COHD, COHU). This jumper is automatically detected by the software application,
and an error message is generated if it is not properly set.
ST1-2, ST1-3 and ST1-4 on controller module are not used. No jumper must be
installed.
ST1 on CPU module (rear corner, left) : for EVS internal tests only (used to reset
the board). Never install that jumper, or the board will be in a permanent reset
state !
LEDS
LEDs on the XNet2 module (SDTI), from left to right:
FRAMER
on (green) when the signal on the XNet or XNet2 IN connector is a valid
EVS SDTI signal.
NET
on (green) when the XNet SDTI network is actually established (SDTI loop
closed, correct speed, etc).
GP not used.
LEDs on the CTL controller module (centre), from left to right:
LED 1 lights red when an error occurs while booting the HCTX board.
LEDs 2 to 8 display the boot sequence of the HCTX board (cf note below).
DSP led blinks green to show DSP activity.
LEDs on the GBE Gigabit module (left), from left to right:
LEDs
CPU1/CPU2
indicates
that the processor is running. The LEDs blink
alternately every 250 milliseconds.
Other LEDs The six other LEDs are for EVS internal use.

EVS XT2+ Specifications

General

Brand	EVS
Model	XT2+
Category	Server
Language	English
