Handling the camera
7
You can assign different functions to the programmable buttons. You can, for example,
use a programmable button to easily switch between two settings you use often. You can
also choose to define two different setups for saving and previewing: the usual setup for
the Save button (which is defined by the Save options and storage settings, see section
23.4 Save options & storage) and another setup for a programmable button.
To assign a function to a programmable button, do the following:
1. Push and hold the programmable button. This displays the Programmable button
menu.
2. Push the navigation pad up/down to select one of the functions. Push the center of
the navigation pad to confirm.
7.12.1 Programmable button options
Available options for the programmable buttons:
• No action: This is the default setting. Nothing will happen when you push the button.
• Switch Auto <> Manual temperature scale: Switch between automatic or manual im-
age adjustment mode. For more information, see section 11.3 Adjusting the infrared
image.
• Autofocus: One-shot autofocus of the infrared camera.
• Continuous autofocus
1
: Switch between the enabled/disabled continuous autofocus
functions.
• Hide image overlay graphics: Switch between hide/show all overlay graphics and im-
age overlay information. For more information, see section 11.8 Hiding all overlay.
• Calibrate: Perform a manual NUC. For more information, see section 11.7 Performing
a non-uniformity correction (NUC).
• Auto-adjust the manual temperature scale: Perform an automatic adjustment of the
image while remaining in manual image adjustment mode.
• Switch Thermal <> Digital camera
1
: Switch between the image modes Thermal and
Digital camera. For more information, see section 12 Working with image modes.
• Switch Thermal <> Thermal MSX: Switch between the image modes Thermal and
Thermal MSX. For more information, see section 12 Working with image modes.
• Switch 1x zoom <> Max zoom: Switch between the digital zoom factor of 1× and max-
imum zoom.
• Switch camera flash On <> Off: Switch between the enabled/disabled camera flash
functions. For more information, see section 7.13 Using the camera lamp as a flash.
Note The flash function will not be activated if the setting Lamp & laser is set to the
option Disable all. For more information, see section 23.5 Device settings.
• Switch single shot <> Video: Switch between the recording modes Single shot and
Video.
• Switch between two latest palettes: Switch between the two last-used color palettes.
For more information, see section 11.5 Changing the color palettes.
• Switch temperature range: Cycle through the camera temperature ranges. For more
information, see section 23.3 Camera temperature range.
• Switch screen rotation On <> Off: Switch between enabled/disabled screen rotation.
• Save: Save an image.
• Save + Prompt for note: Save an image and display the note annotation tool.
• Save + Prompt for table: Save an image and display the table annotation tool.
• Save + Prompt for voice annotation: Save an image and display the voice annotation
tool.
• Save + Prompt for sketch: Save an image and display the sketch annotation tool.
• Save + Select annotation from menu: Save an image and display the annotation tool
menu.
• Preview: Display a preview image.
• Preview + Prompt for note: Display a preview image and the note annotation tool.
• Preview + Prompt for table: Display a preview image and the table annotation tool.
#T810413; r. AF/83467/83910; en-US
30
1. This item is dependent on the lens model.
