FLIR T8 Series User Manual

Achieving a good image11
11.3.5 Manual adjustment in Level, Span mode
Note This procedure assumes that you have configured the camera for manual image
adjustments in Level, Span mode. Select Settings > Device settings > User interface op-
tions > Manual adjustment mode = Level, Span.
Follow this procedure:
1. In live mode, touch the soft button
to enter manual image adjustment mode.
2. Push the navigation pad up/down to increase/decrease the level.
3. Push the navigation pad left/right to increase/decrease the span.
11.3.6 Manual adjustment in Level, Max, Min mode
Note This procedure assumes that you have configured the camera for manual image
adjustments in Level, Max, Min mode. Select Settings > Device settings > User interface
options > Manual adjustment mode = Level, Max, Min.
Follow this procedure:
1. In live mode, touch the soft button
to enter manual image adjustment mode.
2. To simultaneously change the temperature scale minimum and maximum limits, push
the navigation pad up/down.
3. To change the minimum limit or the maximum limit, do the following:
• Push the navigation pad left/right to select (highlight) the maximum or minimum
temperature.
• Push the navigation pad up/down to change the value of the highlighted
temperature.
11.4 Changing the camera temperature range
The camera is calibrated for different temperature ranges. Available temperature range
options are dependent on the camera model.
For accurate temperature measurements, you must change the Camera temperature
range setting to suit the expected temperature of the object you are inspecting.
Note For more information, see section 27 About calibration.
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Settings) and push the navigation pad. This displays the Settings menu.
3. Select Camera temperature range and push the navigation pad. This displays a dia-
log box.
4. Select the appropriate temperature range and push the navigation pad.
Note You can also assign the function Switch temperature range to one of the program-
mable buttons. For more information, see section 7.12 Programmable buttons.
11.5 Changing the color palettes
You can change the color palette that the camera uses to display different temperatures.
A different palette can make it easier to analyze an image.
#T810413; r. AF/83467/83910; en-US
54
