FLIR T8 Series User Manual

Annotating images15
Vault
Door
<ObjectID>
A1a1
A1b2
A1c3
<Deviation>
Overload
Moisture
Draft
<Remedy>
Replace
Fix
No action
<Severity>
Critical
Non-critical
<Severity>
15.4 Adding a voice annotation
A voice annotation is an audio recording that is saved to the infrared image file. The re-
cording can be played back in the camera, and in image analysis and reporting software
from FLIR Systems.
The voice annotation is recorded using the built-in microphone. You can also use a Blue-
tooth-enabled headset. For information on how to pair a headset with the camera, see
section 21 Pairing Bluetooth devices.
Follow this procedure:
1. Open the image in the image archive.
2. Push the navigation pad to display the top toolbar.
3. On the top toolbar, select the
icon and push the navigation pad.
4. On the right toolbar, select the
icon and push the navigation pad.
5. A context menu is displayed.
6. To start a recording, select
(Record) and push the navigation pad.
7. To stop the recording, select
(Stop) and push the navigation pad.
8. To listen to the recording, select
(Play) and push the navigation pad.
9. To delete the recording, select
(Delete) and push the navigation pad.
10. When completed, select
(Done) and push the navigation pad.
15.5 Adding a sketch
You can add a freehand drawing to an infrared image.
Follow this procedure:
1. Open the image in the image archive.
2. Push the navigation pad to display the top toolbar.
3. On the top toolbar, select the
icon and push the navigation pad.
4. On the right toolbar, select the
icon and push the navigation pad.
5. You are now in sketch mode. Draw the sketch by touching the screen.
#T810413; r. AF/83467/83910; en-US
74
