Power Logger
Licensed Features
51
To analyze the data using the PC software:
1. Attach the USB flash drive to a PC with Energy
Analyze installed.
2. In the software, click Download and copy the logging
session and screenshot from the USB flash drive.
3. Open the downloaded session and view the measured
data.
4. Go to the Project Manager tab and click Add Image to
add the screenshot.
For more information about how to use the Energy
Analyze, see the online help for the software.
Licensed Features
License keys are available as optional accessories to
extend the functionality of the Logger with licensed
features.
Table 6 shows the available licensed features:
Table 6. Optional License Features
Feature 1736 1738
WiFi Infrastructure
[1]
• •
1736/Upgrade •
IEEE 519/Report • •
[1] The WiFi Infrastructure license is complimentary and
enabled when you register the Logger at www.fluke.com.
WiFi Infrastructure
This license activates the connection to a WiFi
infrastructure. See page 58 for details.
1736/Upgrade
The upgrade license activates the advanced analysis
features of the 1738 on a 1736 Logger.
Features are:
• Power Quality assessment according to EN 50160:
"voltage characteristics of electricity supplied by public
distribution networks."
This includes the PQ Health logging overview screen
with pass/fail indication of all supported PQ
To Next Page
