Installing the FortiGate unit
This section provides information on installing and setting up the FortiGate unit on
your network. This section includes the following topics:
• Package Contents
• Air Flow
• Mechanical loading
• Powering on the FortiGate unit
• Connecting the FortiGate unit
Package Contents
Review the contents of your FortiGate package to ensure all components were
included.
FortiGate-3000
The FortiGate-3000 package contains the following items:
• FortiGate-3000 Unified Threat Management System
• one orange crossover Ethernet cable (Fortinet part number CC300248)
• one gray straight-through Ethernet cable (Fortinet part number CC300249)
• one null-modem cable (Fortinet part number CC300247)
• two 19-inch rack mount brackets
• two power cables
• FortiGate-3000 QuickStart Guide
• Fortinet Tools and Documentation CD
Figure 1: FortiGate-3000 package contents
1, 2, 3, 4/HA
Interface
External
Interface
Internal
Interface
Front
Back
Power
Supply
LEDs
Power
Connections
Power Cables (2)
Rack-Mount Brackets
Null-Modem Cable
(RS-232)
Documentation
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
USER MANUAL
FortiGate-3000
QuickStart Guide
Copyright 2003 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
POWER
Hi-Temp
12
3
INT
EXT
4/HA
Esc Enter
LCD
Display
Control
Buttons
123 4/HA INTERNAL EXTERNAL
RS-232 Serial
Connection
POWER
Hi-Temp
12
3
INT
EXT
4/HA
Esc Enter
123 4/HA INTERNAL EXTERNAL
