TGA100 Rev0106
24
Figure 6. Pressure Sensor Wiring
Pressure Sensor
From Control Module
12-Pin Connector
Pressure
Sensor Cable
Pressure
Sensor
Pressure Sensor
(Top View)
Supply
Voltage
Signal
Output
Ground
Pressure Sensor Cable
3-Pin Sensor Connector
Pin/Wire Description
A/Black Ground
B/Red Supply Voltage
C/White Signal Output
