FRC InControl TGA100 User Manual

TGA100 Rev0106
8
Controls and Indicators
All controls and indicators are located on the front of the control module. (Refer
to Figure 1.) The LED digital display has daylight bright digits at least 0.56 inch high.
PUMP DISCHARGE Display
Shows the pump discharge pressure during normal operations.
PSI LED
The red PSI LED is on to indicate operation in the pressure mode.
PSI Button
Selects the pressure mode of operation.
PRESET Button
Press to change/select a pre-programmed value for pressure or RPM setting..
PSI/RPM Setting Display
The display will show the pressure or the RPM setting.
RPM Button
Selects the RPM mode of operation.
RPM LED
The red RPM LED is on to indicate operation in the RPM mode.
RPM Display
Shows the engine RPM during normal operations.
SILENCE Button
Suppresses audio alarms.
VOLTS LED Display
Shows battery voltage. LEDs will flash when the voltage is outside normal limits.
TRANS. °F LED Display
Shows transmission temperature. LEDs will flash when the temperature high.
°F LED Display
Shows engine coolant temperature. LEDs will flash when the temperature high.
PSI LED Display
Shows engine oil pressure. LEDs will flash when the pressure low.
