3.3 Auto Layout 31
Example:
Assume that the following data is input when Zoom Mode = Output Size, Origin Position =
Auto, Paper Margin = 10 mm, Area Determine = IP.
All pen width are set to 0.1 mm.
The following data does not contain a character size specification command and the
physical size of the area specified by IP/IW is A3.
IN;
IP -8399, -5938, 8399, 5938;
IW -8399, -5938, 8399, 5938;
PU;
SP1;
:
:
SP0;
1. [Area Determine] is set to [IP], so the area (-8399, -5938, 8399, 5938) specified by the
IP command is determined as the effective coordinate area.
2. The data in the above example contains no character size specification command and
all pen widths are 0.1 mm, so the size that is one-half the default height of the
character on A3 paper (75 plotter unit) is added to the size of the effective coordinate
area obtained by 1.
Effective coordinate area obtained by 2: -8474, -6013, 8474, 6013
3. The area specified by [Paper Margin] (10 mm = 400 plotter unit) is removed from the
effective coordinate area obtained by 2.
Effective coordinate area obtained by 3: -8074, -5613, 8074, 5613
4. The effective coordinate area obtained by 3 is of the A3 size (greater than the A4
size), so the file size is determined as being A3.
The effective coordinate area obtained when [Paper Margin] is set to [0mm] is (-8474,
-6013, 8474, 6013), so its size is greater than A3 up to A2 inclusive. The file size is
determined as being A2.
Determining the Output Size
When the following settings are made on the control panel, the paper size is determined as
described below.
• File Size: Auto
• Paper Supply: Auto
The method of determining the paper size varies depending on the [Output Size] setting and
[Zoom Mode] setting on the control panel.
When [Output Size] Is Set to [A size]
Candidate paper sizes for the paper actually loaded in the tray are A3, A4, and A5.
If A-size (A3, A4, A5) paper is not loaded in the tray, an error message appears on the
control panel display prompting you to load A-size paper.
