6.1 Clearing Paper Jams 133
Paper Jams in the Bypass Tray
1. Leave the jammed paper where it is and
remove the rest of the paper from the
bypass tray.
2. Push up the lever A and open the front
cover.
Important
• When opening the front cover with the bypass tray
cover opened, be careful not to get your fingers
caught between (the left or right edge of) the bypass
tray cover and the front cover.
3. Remove the jammed paper.
4. Close the front cover.
Important
• When closing the front cover, be careful not to get your
fingers caught between (the left, right, top, or bottom
edge of) the cover and the printer.
To Next Page
