Fujitsu ScanSnap S1300 Installation And Troubleshooting Guide

If you have installed the software before
15
z For Windows 2000
1. Select [Start] menu → [Settings] → [Control Panel] → [Add/Remove Programs].
D A list of installed software is displayed.
2. Select a software to uninstall.
The following software must be uninstalled:
- ScanSnap Manager
- ScanSnap Organizer
- CardMinder
3. Click the [Remove] button.
D A confirmation message appears.
4. Click the [Yes] button.
D The software is uninstalled.
5. Confirm that the software has been removed from the list in [Add/Remove
Programs].
ATTENTION
For S1300i and S1100, Windows 2000 is not supported.
HINT
To uninstall more than one software, repeat steps 2. to 5. for each software.
z If the software no longer exists in the list, it indicates that uninstallation was successful. Proceed to
"Installing the software from the [ScanSnap Setup] dialog box" (page 20).
z If the software still remains in the list, proceed to the next topic "Removing the installation information"
(page 16).

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
