Fujitsu ScanSnap S1300 Installation And Troubleshooting Guide

When the ScanSnap Manager icon does not appear
24
When the ScanSnap Manager icon does not
appear
This section explains how to troubleshoot when the ScanSnap Manager icon does not
appear on the taskbar even though you installed the software and connected the ScanSnap to
the computer.
■ Displaying the ScanSnap Manager icon
1. Select [Start] menu → [All Programs] → [ScanSnap Manager] →
[ScanSnap Manager].
HINT
If ScanSnap Manager starts up, you can then configure the setting to automatically start ScanSnap
Manager from the next time you log on.
Perform the following procedure.
1. Right-click the ScanSnap Manager icon on the taskbar, and then select [Help] →
[Preferences] from the menu that appears.
DThe [ScanSnap Manager - Preferences] dialog box appears.
2. Select the [Start up ScanSnap Manager when you log on] check box in the [Auto Startup] tab.
If the problem persists, refer to the next topic "When ScanSnap Manager does not operate normally"
(page 25).

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
