Fujitsu ScanSnap S1300 Installation And Troubleshooting Guide

When ScanSnap Manager does not operate normally
26
■ Checking if ScanSnap Manager is operating normally
1. Turn the ScanSnap off then back on.
Make sure to leave at least five seconds between turning the power ON/OFF.
2. If you are using a USB hub, connect the ScanSnap to the computer
directly with a USB cable.
3. If a USB device other than the ScanSnap is connected to the computer,
disconnect it.
4. If an anti-virus software is running, disable the software temporarily.
5. If there is more than one USB port on the computer, connect the USB
cable to a different USB port.
If the problem persists, proceed to 2.
If the problem persists, proceed to 3.
If the problem persists, proceed to 4.
ATTENTION
If you cannot disable the anti-virus software, check if the software is set to lock the application.
If the problem persists, proceed to 5.
If the problem persists, proceed to 6.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
