1. OPERATION
12
• The TX pulse length changes according to
ACCU-FISH
TM
On/Off state. This causes a
difference in both sensitivity and the ech-
oes viewed.
1.15.1 How to activate
ACCU-FISH
TM
ACCU-FISH
TM
is inoperative when the trans-
ducer type is selected to 600W or 1kW FCV-
587 only), on the [Transducer] menu.
1. Open the menu, select [Display] and
press the ENTER key.
2. Select [ACCU-FISH] and press the EN-
TER key to show the [ACCU-FISH] menu.
3. Select [ACCU-FISH] and press the EN-
TER key.
4. Select [On] to enable ACCU-FISH
TM
.
1.15.2 Fish symbols
1. Open the menu, select [Display] and
press the ENTER key.
2. Select [ACCU-FISH] and press the EN-
TER key to show the [ACCU-FISH] menu.
3. Select [Fish Symbols] and press the EN-
TER key.
[Fish Symbols] setting box
4. Select desired symbol and press the EN-
TER key. The size of the symbol is scaled
according to the estimated length of the
fish.
Note: To hide the fish symbol, select [Off]
at step 4 and press the ENTER key.
Note: You can select which frequency display
to show the fish symbols and fish information,
with [Symbols Area] on the [ACCU-FISH]
menu.
• [Dual]: Symbols and info shown on both HF
and LF displays.
• [HF]: Symbols and info shown on HF dis-
play.
• [LF]: Symbols and info shown on LF dis-
play.
1.15.3 Fish info
1. Open the menu, select [Display] and
press the ENTER key.
2. Select [ACCU-FISH] and press the EN-
TER key to show the [ACCU-FISH] menu.
3. Select [Fish Info] and press the ENTER
key.
4. Use S or T to select [Off], [Fish Size] or
[Depth] as appropriate and press the EN-
TER key.
Note 1: You can show the fish info figure
alone (without fish symbol) by turning off
[Fish Symbols] on the [Display] menu.
Note 2: You can show the fish info in
small or large characters, with [Info Size]
on the [ACCU-FISH] menu.
Striped
Solid Circle Square
Large fish symbol
(more than 50 cm, or
more than 20 inches)
Small fish symbol
(10 to 49 cm, or 4 to
19 inches)
Fish length or depth
is shown in red.
To Next Page
