4. INSTALLATION
4.1 Equipment List
Standard supply for FCV-627
Standard supply for FCV-587
Name Type Code No. Qty Remarks
Display Unit CV-627-E -
Select
one
With hard cover
E: English panel
C: Chinese panel
CV-627-C -
Installation
Materials
CP02-07900 - 1 set • Cable Assy. (Type: KON-004-02M,
Code No.: 000-156-405-12)
• Self-tapping Screw (Type: 5×25,
Code No.: 000-162-610-10, 4 pcs.)
Spare Parts SP02-05001 001-384-040 1 set Fuse (Type: FGBO-A 125V 2A PBF,
Code No.: 000-155-849-10, 2 pcs.)
Accessories
Type:
FP02-05501
Code No.:
001-384-090
Qty: 1 set
Contents
• LCD Cleaning Cloth (Type: 02-155-1082-2, Code No.: 100-332-652-10)
• Large MJ Cable Cap (Type: 02-154-1221-1, Code No.: 100-329-441-10)
• Flush Mounting Sponge (Type: 02-154-1601, Code No.: 100-329-460-10)
• Wing Nut (Type: M4, Code No.: 000-167-545-10, 4 pcs.)
• Flat Washer (Type: M4, Code No.: 000-167-455-10, 4 pcs.)
• Spring Washer (Type: M4, Code No.: 000-167-405-10, 4 pcs.)
• Threaded Rod (Type: M4×50, Code No.: 000-162-679-10, 4 pcs.)
Name Type Code No. Qty Remarks
Display Unit CV-587-E -
Select
one
With hard cover
E: English panel
C: Chinese panel
CV-587-C -
Installation
Materials
CP02-07900 - 1 set • Cable Assy. (Type: KON-004-02M,
Code No.: 000-156-405-12)
• Self-tapping Screw (Type: 5×25,
Code No.: 000-162-610-10, 4 pcs.)
Spare Parts SP02-05001 001-384-040 1 set Fuse (Type: FGBO-A 125V 2A PBF,
Code No.: 000-155-849-10, 2 pcs.)
Accessories
Type:
FP02-05601
Code No.:
001-384-260
Qty: 1 set
Contents
• LCD Cleaning Cloth (Type: 02-155-1082-2, Code No.: 100-332-652-10)
• Large MJ Cable Cap (Type: 02-154-1221-1, Code No.: 100-329-441-10)
• Flush Mounting Sponge (Type: 02-155-1081-1, Code No.: 100-330-851-10)
• Wing Nut (Type: M4, Code No.: 000-167-545-10, 4 pcs.)
• Flat Washer (Type: M4, Code No.: 000-167-455-10, 4 pcs.)
• Spring Washer (Type: M4, Code No.: 000-167-405-10, 4 pcs.)
• Threaded Rod (Type: M4×50, Code No.: 000-162-679-10, 4 pcs.)
