Furuno FM-7000 User Manual

FELCOM 81
H2-3
The default settings are shown in a screened cell of each setting item.
Setting item
Unit Function
Setting Note
OFF: Direct call
No.1 TEL:
- Register the TEL number: *51* LES
00 Country code xxxxxxx #
- Clear the registered number: *51*#
SW Panel
DIP SW#1
Automatic call
ON: Address call
Call start with reception of DTR
signal from HSD terminal.
OFF: RS-449
SW Panel
DIP SW#2
Terminal
Interface
ON: RS-232C
Interface with HSD terminal.
RS-449:D-SUB 37pin
RS-232C: D-SUB 25pin
Never use both RS-232C and RS-449
terminal on the HSD modem at the
time.
OFF: NO SW Panel
DIP SW#3
Automatic data
rate switching
ON: YES
OFF: HDCL SW Panel
DIP SW#4
Command
format
ON: BSC
- High level data link control
- Binary synchronous communication
OFF: 8 bit/no parity SW Panel
DIP SW#5
Character
format
ON: 7 bit/odd parity
64k
IB-681
Date rate SW Data rate
56k
56k is for USA ISDN circuit
Reference: IB-681)
Registering, Deleting Subscriber Number
Register subscriber number as follows with the No.1 telephone. The subscriber number
may contain 20 digits (*,# cannot be registered). The number can be confirmed by
printing the status display.
1. Pick up the handset of the No.1 telephone and confirm dial tone.
2. Dial subscriber’s No. as follows;
*51* aaa 00 bb xxxxxxxxx #
subscriber number
Country code
Automatic Dialing
Land Earth Station (LES)
Prefix for HSD call
Deleting subscriber number
Dial [*] [5] [1] [*] [#].
