Furuno FM-7000 User Manual

Appendix
AP1-10
Type of Coaxial cable and loss in 1600 MHz
Loss (dB)
Type
10m 20m 30m 40m 50m 60m 70m 80m 90m 100m
3D-2V 8 16 24 32 40 48 56 64 72 80
5D-2V 4.4 8.8 13.2 17.6 22 26.4 30.8 35.2 39.6 44
8D-2V 3.3 6.6 9.9 13.2 16.5 19.8 23.1 26.4 29.7 33
10D-2V 2.7 5.4 8.1 10.8 13.5 16.2 18.9 21.6 24.3 27
5D-FB 2.6 5.2 7.8 10.5 13 15.6 18.2 20.8 23.4 26
8D-FB 1.8 3.6 5.4 7.2 9 10.8 12.6 14.4 16.2 18
10D-FB 1.5 3 4.5 6 7.5 9 10.5 12 13.5 15
RG-174/U 12 24 36 48 60 72 84 96 108 120
RG-58A/U 7.9 15.8 23.7 31.6 39.5 47.4 55.3 63.2 71.1 79
RG-213/U 3.9 7.8 11.7 15.6 19.5 23.4 27.3 31.2 35.1 39
RG-55A/U 6.1 12.2 18.3 24.4 30.5 36.6 42.7 48.8 54.9 61
RG-5B/U 4.4 8.8 13.2 17.6 22 26.4 30.8 35.2 39.6 44
RG-214/U 3.7 7.4 11.1 14.8 18.5 22.2 25.9 29.6 33.3 37
RG-217/U 2.9 5.8 8.7 11.6 14.5 17.4 20.3 23.2 26.1 29
RG-222/U 19 38 57 76 95 114 133 152 171 190
