Furuno FR-2115/2125 User Manual

4-16

J475
J474
J473
J472
J471
J451
A
A
Pan-head Screw
M3X8, 4 pcs.
Cable Tie CV-100,
2 pcs.
ALARM Board
03P9262
NH Connector
03-1991(3P), 4 pcs.
Pan-head screw
M4X12
Cable Band
HP-3N
INT Board
03P9252
NH Connector
03-1990(9-9P)
Pass cable
through here.
Existing cable tie
Figure 4-16 Display unit, inside view
20 mm
Shrink Tubing
HOW TO INSULATE THE POWER CABLE
2 Solder power
cable to signal cable.
3
Heat shrink
tubing with solder-
ing iron.
Solder
1 Make length of
shrink tubing 20 mm;
slip tubing onto wiring.
