FELCOM
80
H1-2
Mul
tiple T
el
ephone/Facsimil
es
Install the PHONE I/F board (standard supply) in the Communication Unit and connect
it to the V
. CODEC board as shown below
.
Connection of more than one tel
ephone requires
Junction Box
IB-31
1.
In this case
the
TEL1 and F
AX1 modular jack on the Communication Unit IB-280 is not used.
IB-31
1
Junction Box
IB-280
Max. TEL 4 ,
F
A
X
2
u
n
i
t
s
277
279
