REMOTE
I1-14
2. Connection to FS-1562, FS-1552, FS-1502 and FS-1503
For the FS-1562;
The REMOTE-A (RS-232C) board on the TX/RX board is replaced with the
REMOTE-B(C.Loop) board (05P0458: 005-517-500).
REMOTE A (RS-232C) board: 05P0457 005517480
REMOTE B (C.Loop) board : 05P0458 005517500
For the FS-1552 and FS-1502;
Install the optional board: REMOTE-B (C.Loop).
The REMOTE-B kit, consists of the REMOTE-B board and the connector assembly.
REMOTE A (RS-232C) Kit : OP05-39 005920310
REMOTE B (C.Loop) Kit : OP05-40 005920320
For the FS-1503;
Install the optional board: REMOTE-B (C.Loop).
The REMOTE-B kit, consists of the REMOTE-B board and the connector assembly.
REMOTE A (RS-232C) Kit : OP05-82 005939810
REMOTE B (C.Loop) Kit : OP05-83 005939820
Note)
If more than two RB-500s are installed, connect them via the Distributor DB-500.
To Next Page
