Gardena R38Li Installation Manual

16 - English
2. PRESENTATION
The control panel on the top of the robotic
lawnmower is where you manage all the robotic
lawnmower settings. Open the control panel cover by
pressing down the STOP button.
When the main switch is set to position 1 for the first
time, a start-up sequence begins which includes
language selection, time format, date format and the
four-digit PIN code and setting the time and date. See
3.8 First start-up and calibration on page 34.
Movement pattern
The robotic lawnmower’s movement pattern is
irregular and is determined by the robotic lawnmower
itself. A movement pattern is never repeated. With
the mowing system the lawn is mown equally without
any mowing lines from the robotic lawnmower.
2.4 Search method
The robotic lawnmower runs irregularly until it reaches
the guide wire. Then the robotic lawnmower follows the
guide wire to the charging station.
The guide wire is a wire that is laid from the charging
station towards, for instance, a remote part of the
working area or through a narrow passage to be then
connected with the boundary wire. For more
information, see 3.6 Installation of the guide wire
on page 34.
Start
1
1 23 4 5
4
78
0
9
56
23
1157069-26,R40Li_GB.book Page 16 Wednesday, November 19, 2014 5:02 PM

Gardena R38Li Specifications

General

Type	Robotic lawn mower
Noise level	58 dB
Display type	LCD
Cutting width	170 mm
Grass catcher	No
Product color	Black, White
Cutting system	-
Number of blades	3
Maximum lawn area	380 m²
Recommended lawn area	- m²
Maximum cutting height	50 mm
Minimum cutting height	20 mm
Grass collecting volume	- L
Suitable for slope up to	25 %
Automatic base station return	Yes
Power source	Battery
Charging time	1 h
AC input voltage	18 V
Battery capacity	1.6 Ah
Battery life (max)	65 min
Power consumption per month (max)	4 kWh

Weight and Dimensions

Depth	580 mm
Width	460 mm
Height	260 mm
Weight	7400 g
