Gardena R38Li Installation Manual

English - 65
8. MAINTENANCE
8.3 Cleaning
It is important to keep the robotic lawnmower clean.
A mower with large amounts of grass stuck to it will not
cope as well with slopes. It is recommended to clean
using a brush.
Chassis and blade disc
1. Set the main switch in position 0.
2. Wear protective gloves.
3. Lift the robotic lawnmower onto its side.
4. Clean the blade disc and chassis using e.g. a
dish brush.
At the same time, check that the blade disc
rotates freely in relation to the foot guard.
If long blades of grass or other objects find their
way in, these may impede the blade disc. Even a
slight braking effect leads to a higher
consumption of energy and longer mowing
times, and at worst will prevent the robotic
lawnmower from being able to mow a large lawn.
Chassis
Clean the underside of the chassis. Brush or wipe
with a damp cloth.
Wheels
Clean around the front wheels and rear wheel as well
as the rear wheel bracket.
IMPORTANT INFORMATION
Never use a high-pressure washer or even
running water to clean the robotic
lawnmower. Never use solvents for cleaning.
1157069-26,R40Li_GB.book Page 65 Wednesday, November 19, 2014 5:02 PM

Gardena R38Li Specifications

General

Type	Robotic lawn mower
Noise level	58 dB
Display type	LCD
Cutting width	170 mm
Grass catcher	No
Product color	Black, White
Cutting system	-
Number of blades	3
Maximum lawn area	380 m²
Recommended lawn area	- m²
Maximum cutting height	50 mm
Minimum cutting height	20 mm
Grass collecting volume	- L
Suitable for slope up to	25 %
Automatic base station return	Yes
Power source	Battery
Charging time	1 h
AC input voltage	18 V
Battery capacity	1.6 Ah
Battery life (max)	65 min
Power consumption per month (max)	4 kWh

Weight and Dimensions

Depth	580 mm
Width	460 mm
Height	260 mm
Weight	7400 g
