English - 49
6. MENU FUNCTIONS
A clock symbol is displayed on the start page when the
timer settings are set. The clock symbol is black when
the robotic lawnmower is not allowed to mow due to a
timer setting and it is white when the mower is allowed
to mow.
The robotic lawnmower has an inbuilt standby period
of about 8 hours a day (11 hours for the GARDENA
R40Li). The robotic lawnmower is parked in the
charging station during this period. See 4.2 Using the
timer on page 37.
6.4 Installation, R70Li, R80Li
The following operating settings are available via this
selection in the main menu.
• Guide width
to select the distance from the guide wire the
robotic lawnmower is allowed to travel when it
follows this to and from the charging station.
• Remote start 1
to control the robotic lawnmower so that it can
easier reach remote parts of the garden.
• Remote start 2
to control the robotic lawnmower so that it can
easier reach remote parts of the garden.
• Test settings
to check the above settings.
• Drive past wire
to set the distance over the boundary wire that
the robotic lawnmower should travel before
turning back.
For examples of garden settings, see 7. Garden
examples.
Guide width
The guide width is a measure of how far from the
guide wire the robotic lawnmower is allowed to travel
when it follows this to and from the charging station.
The area beside the wire which the robotic
lawnmower then uses is called the Corridor.
The robotic lawnmower has a default setting for
medium wide corridors. To further reduce the risk of
tracks forming, it is recommended to select a wide
corridor in working areas where it is possible to do so.
IMPORTANT INFORMATION
Always use as wide a guide width as
possible. The Narrow setting must only be
used when none of the other settings can be
used in the working area in question.
Guide width
Remote start 1
Remote start 2
Test settings
Drive past wire
Timer
Installation
Security
Settings
Guide width
Remote start 1
Remote start 2
Test settings
Drive past wire
Narrow
Medium
Wide
1157069-26,R40Li_GB.book Page 49 Wednesday, November 19, 2014 5:02 PM

Gardena R38Li Specifications

General

Type	Robotic lawn mower
Noise level	58 dB
Display type	LCD
Cutting width	170 mm
Grass catcher	No
Product color	Black, White
Cutting system	-
Number of blades	3
Maximum lawn area	380 m²
Recommended lawn area	- m²
Maximum cutting height	50 mm
Minimum cutting height	20 mm
Grass collecting volume	- L
Suitable for slope up to	25 %
Automatic base station return	Yes
Power source	Battery
Charging time	1 h
AC input voltage	18 V
Battery capacity	1.6 Ah
Battery life (max)	65 min
Power consumption per month (max)	4 kWh

Weight and Dimensions

Depth	580 mm
Width	460 mm
Height	260 mm
Weight	7400 g
