3. INSTALLATION
3.9 Test docking with the charging
station
Before using the robotic lawnmower, check that the
robotic lawnmower can follow the guide wire all the
way to the charging station and easily docks with the
charging station. Perform the test below.
1. Open the control panel cover by pressing the
STOP button.
2. Place the robotic lawnmower close to the point
where the guide wire is connected to the boundary
wire. Place the robotic lawnmower about 2 metres
from the guide wire, facing the guide wire.
3. Select Home mode by pressing the house symbol
key and pressing OK when the cursor is at Home.
Press Start and close the cover.
4. Check that the robotic lawnmower follows the
guide wire all the way to the charging station and
that it docks with the charging station. The test is
approved only if the robotic lawnmower is able to
follow the guide wire the entire distance to the
charging station and docks at the first attempt. If
the robotic lawnmower is unable to dock on the
first attempt, it will automatically try again. The
installation is not approved if the robotic
lawnmower needs two or more attempts to dock
with the charging station. In this case, check that
the charging station, the boundary wire and the
guide wire are installed in accordance with the
instructions in Chapters 3.2, 3.4 and 3.6.
5. The robotic lawnmower will stay in the charging
station until Auto or Man mode is selected. See
5.1 Operation selection on page 41.
The guide system must first be calibrated if the above
test is to provide a satisfactory result. See 3.8 First
start-up and calibration on page 34.
1157069-26,R40Li_GB.book Page 35 Wednesday, November 19, 2014 5:02 PM

Gardena R38Li Specifications

General

Type	Robotic lawn mower
Noise level	58 dB
Display type	LCD
Cutting width	170 mm
Grass catcher	No
Product color	Black, White
Cutting system	-
Number of blades	3
Maximum lawn area	380 m²
Recommended lawn area	- m²
Maximum cutting height	50 mm
Minimum cutting height	20 mm
Grass collecting volume	- L
Suitable for slope up to	25 %
Automatic base station return	Yes
Power source	Battery
Charging time	1 h
AC input voltage	18 V
Battery capacity	1.6 Ah
Battery life (max)	65 min
Power consumption per month (max)	4 kWh

Weight and Dimensions

Depth	580 mm
Width	460 mm
Height	260 mm
Weight	7400 g
